At SAE WCX 2024, Sandy Munro delivered a powerful presentation that captivated automotive engineers, investors, and EV enthusiasts alike. Drawing on hands-on teardown insights and lean manufacturing principles, Munro’s talk focused on what he calls “the most exciting vehicle” of his 75-year life: the Tesla Cybertruck.

This analysis dives into Munro’s key observations on powertrain design, thermal management, battery safety, 48V architecture, and gigacasting. And, importantly, these are all essential elements shaping the future of electric vehicle (EV) engineering.


Radical Battery Venting and Safety Innovation

One of the standout Cybertruck features is a deceptively small yet revolutionary component: the new battery pack venting system. Traditional EV batteries face thermal runaway risks, often resulting in fire or explosion. Tesla’s Cybertruck introduces a dual-layer solution: a pressure-relief vent to safely release gases and a built-in spark arrester to prevent ignition of nearby flammable materials.

This innovation addresses both altitude-based pressure changes and emergency thermal events—showcasing Tesla’s attention to safety and detail in battery design. As Sandy emphasized, no other automaker has implemented such a precise gas-and-spark management system at the cell level. It’s the kind of forward-thinking engineering other OEMs will inevitably follow.


Evolving Motor Architecture and Cost-Effective Modularity

The Cybertruck’s tri-motor layout impressed even seasoned teardown veterans. Contrary to previous Tesla configurations, the vehicle positions two induction motors in the rear and a permanent magnet (PM) motor up front. This inversion reduces parasitic drag when the induction motors are disengaged—boosting range efficiency.

What’s more striking is Tesla’s harmonization of motor diameters. Both the PM and induction motors share the same shaft diameter and housing dimensions. This subtle yet impactful decision allows Tesla to use a single machine to wind both types of stators—simplifying manufacturing and slashing cost and complexity. Munro lauded the move as a triumph of lean design, optimizing tooling reuse and reducing weight and waste.

The PM motor also features a partially exposed keeper plate that enhances direct oil-cooling—something unseen in previous Tesla or competitor builds. Combined with rotor design changes, the Cybertruck motor package promises increased power density and superior thermal management.


Cold Forging and Hairpin Winding Advance the State of the Art

Tesla continues to leap ahead with cold near-net forgings and advanced stator winding. Munro, drawing on 50 years of experience, noted how few companies ever take the necessary risks. As a result, most fall short of reaching this level of innovation. Yet Tesla replaced traditional wound stators with compact hairpin-style conductors and cold-formed forgings—reducing waste and improving performance.

Although not as advanced as Lucid’s woven grid design, the Cybertruck’s implementation still marks a major shift toward efficient, scalable EV manufacturing. Munro called it “as modern as we can get right now,” emphasizing Tesla’s push to evolve even foundational components.


The 48V Revolution: Lighter, Faster, Cheaper

One of the biggest applause points during Munro’s speech came from his passionate endorsement of Tesla’s switch from 12V to 48V systems. As he described, this architectural shift dramatically reduces copper use, cable thickness, and connector cost.

Tesla quadruples voltage while keeping power constant. This reduces wire cross-sections. The result is up to 65% weight savings in the Cybertruck’s electronic architecture. Moreover, Tesla replaces bulky CAN bus systems with Ethernet-based loops and flat ribbon cables. These alternatives are lighter, faster, and cheaper.

Munro called out traditional OEMs for their reluctance to embrace 48V, citing a personal anecdote where his advocacy of the idea was deemed a “career-limiting move.” Tesla stands out for bold engineering and supply chain flexibility. When suppliers fall behind, Tesla makes its own connectors and sensors. And it sets them apart.


Mega Castings: Floor Space, Cost, and Time Slashed

Tesla’s gigacastings were a central highlight. At Munro’s teardown lab, side-by-side comparisons of Model Y and Cybertruck castings revealed Tesla’s evolution in design, CFD modeling, and material optimization.

Using proprietary CAD and fluid dynamic simulations, Tesla reduced tonnage requirements for massive aluminum castings—eliminating welds and cutting cycle times to under one second. This not only reduces thermal stress and improves quality, but also slashes production costs.

According to Sandy, Tesla saved nearly $200 per vehicle and reduced floor space needs by 40%. He challenged skeptics with a simple demonstration: hitting both cast and stamped metal with a 12-pound sledgehammer. The casting absorbed the blow with minor paint damage; the stamped panel collapsed. His takeaway: stop spreading myths—cast aluminum can be both strong and crash-resilient.


Smarter Use of Scrap Through Secondary Castings

Another clever efficiency is Tesla’s use of mixed-material secondary castings for non-structural areas, such as the Cybertruck’s tambour door supports. Munro explained that these are likely made from remelted scrap—an environmentally and economically savvy choice.

These parts retain the same snap-fit, easy-assembly design as main structural elements, but avoid unnecessary strength (and cost) where it’s not needed. As Munro put it: “Design for what it needs to be—not for what somebody else thinks would be a good idea.”


The Casting vs. Stamping Debate: A Designer’s Reality

Drawing on decades of experience with Mitsubishi’s Normal, Illinois plant and a career in die-making, Munro offered a data-driven case for replacing stamped sub-assemblies with castings.

With castings, automakers eliminate expensive stamping dies, coilers, weld cells, and storage areas. Munro presented real-world floorplan savings and capital reductions, reiterating that long-term cost, not just press expense, should drive manufacturing decisions.

As he concluded: “We have to start saying yes—and we have to do it in a hurry.”


A Call to Action for Engineers and OEMs

Sandy Munro’s keynote wasn’t just a teardown review—it was a rallying cry. He urged engineers to move faster, think leaner, and embrace bold choices in material science, voltage architecture, and manufacturing innovation.

Tesla’s Cybertruck is more than a radical-looking EV—it’s a case study in what’s possible when design, engineering, and manufacturing align. From high-voltage systems and modular motors to casting breakthroughs and smart reuse strategies, it’s a masterclass in next-generation automotive thinking.
